BJW86-120/25 Explosion-proof temperature controller

Explosion-proof temperature controller for electric heating cable

The explosion-proof temperature controller is an important accessory of the electric heating system, used to control the temperature of the heating medium, and is used in conjunction with the FDH type general explosion-proof junction box

Technical indicators:

1. Model: BJW86

2. Rated current: 25A

3. Temperature adjustment range: 0-120℃, 0-150℃, 0-200℃

4. Temperature control accuracy: ±5℃

5. On-off differential: ≤6℃

6. Inner diameter of control cable sealing ring: ⊿14mm

7. Protection level: IP65

Product introduction:

The explosion-proof temperature controller is an important accessory of the electric heating system, used to control the temperature of the heating medium, and is used in conjunction with the CH type general explosion-proof junction box. It is designed and manufactured according to the requirements of explosion-proof electrical appliances, and the explosion-proof mark is: “Exd e mb llCT4 Gb”;  its shell is DMC plastic with the characteristics of light weight, high mechanical strength and strong corrosion resistance.
