Constant Wattage Heating Cables - Silicone Belts

Product introduction: silicone sheet electric tropical, for thin sheet heating products (standard thickness is 1.5mm), it has a good flexibility, can be wrapped like a rope around the pipe and other heating body outside with temperature tape fixed, can also be directly wrapped in the heating body outside with a spring hook fixed, such as adding insulation layer, heating performance is better. Its heating element is made of nickel-chromium wire two buns with thermal insulating silicone material, formed by high temperature molding, so the safety performance is very reliable, pay attention to avoid overlapping winding installation, so as not to affect the heat transfer, thus affecting the service life of the product.

[email protected]

WhatsApp:17816879390

Send Inquiry

Product Description

Constant Wattage Heating Cables

1. silicone sheet electric tropical

2. Technical parameters

1) Maximum temperature resistance of insulation material: 300℃

2) Maximum operating temperature: 250℃

3) Insulation resistance: ≥200 MΩ

4) Compressive strength: ≥AC1500v/5s

5) Power deviation: ±5%

6) Voltage range: 1.5-380v

7) Maximum unit power: 2.1w/cm2

3. Conventional size

dimension（mm）	power（W）	voltage（v）
1000151.5/3.5	90W	220
2000151.5/3.5	180W	220
3000151.5/3.5	270W	220
1000201.5/3.5	120W	220
2000201.5/3.5	240W	220
3000201.5/3.5	360W	220
1000251.5/3.5	150W	220
2000251.5/3.5	300W	220
3000251.5/3.5	450W	220
Longest 10m	Maximum 10KW/M	220

Note: Beyond the above size, can be customized according to the user needs voltage, power, specifications size production installation method:

4. Main applications:

● Industrial equipment pipes, barrels, containers

● Outdoor communication equipment, electronic devices

● Medical equipment, medical equipment

● Thermal development of thermal transfer equipment and imaging equipment

● Protect enclosures, industrial ovens and hot processing equipment in cold, wet environments

● Battery pack insulation

2. extrusion silicone electric tropical zone

Silicone rubber extrusion heat belt has excellent softness and excellent water resistance, and is generally suitable for heating, heating and insulation of industrial equipment or laboratory pipelines, tanks and tanks in humid and non-explosive gas places.

All silicone electric heating products of the company can be customized according to the voltage, size, shape and power required by customers

Heating Cables

Send Inquiry

For inquiries about our products or pricelist, please leave your email to us and we will be in touch within 24 hours.

Product Categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Related Products

silicone parallel type constant power heating cable

The Qingqichen silicone heating cable is a parallel type constant power heating cable, which is characterized by independent heating of each circuit contact. The lowest tolerance is -70°, and the highest surface temperature resistance can reach +200°C. With great flexibility, this type of heating cable is particularly suitable for industrial refrigeration due to its extreme low temperature and can be installed in the cold storage door. In order to ensure that these electric heating elements have a long service life, we recommend the use of a control device.

Silicone heater

The silicone heating element is made by pressing two pieces of semi-cured silicone cloth together using high-temperature equipment. The silicone skin is very thin, which gives it excellent thermal conductivity. It is flexible and can adhere perfectly to curved surfaces, cylinders, and other objects that require heating.

Self-Regulating Silicone Rubber Heating Cable Belt for Compressor

Due to the relationship between the temperature and the resistance value of PT100 thermal resistance, people use this characteristic to invent and produce PT100 thermal resistance temperature sensor. It is an intelligent sensor integrating temperature and humidity collection. The temperature collection range can be from -200°C to +850°C, and the humidity collection range is from 0% to 100%.

Silicone strap

Silicone sheet electric heating belt is a thin strip heating product (standard thickness is 1.5mm). It has good flexibility and can be wrapped around a pipe or other heating body with heat-resistant tape to fix it like a rope, or it can be directly wrapped in a heated The outside of the body is fixed with a spring hook, and the heating performance is better if an insulation layer is added. The heating element is made of nickel-chromium wire wrapped with heat-conducting and insulating silicone material, which is molded at high temperature, so the safety performance is very reliable. Pay attention to avoid overlapping winding installation as much as possible, so as not to affect heat transfer and affect the service life of the product.
